Warehouse Hydraulic Dock Lift ,Scissor Truck Lifts For Container Load Solution

Warehouse Hydraulic Dock Lift ,Scissor Truck Lifts For Container Load Solution
Warehouse Hydraulic Dock Lift ,Scissor Truck Lifts For Container Load Solution Warehouse Hydraulic Dock Lift ,Scissor Truck Lifts For Container Load Solution Warehouse Hydraulic Dock Lift ,Scissor Truck Lifts For Container Load Solution

Large Image :  Warehouse Hydraulic Dock Lift ,Scissor Truck Lifts For Container Load Solution

Product Details:
Place of Origin: China
Brand Name: Kinglift
Certification: CE
Model Number: KLSJG3-1.35
Payment & Shipping Terms:
Minimum Order Quantity: 1unit
Price: Negotiable
Packaging Details: Wrapped in bubble wrap
Delivery Time: 10-15days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 120sets/month
Detailed Product Description
Product Name: Warehouse Hydraulic Dock Lift Other Names: Scissor Truck Lifts
Load Ability: 3000kg Table Size: 2000*2500mm Or Customization
Lifting Height: 1350mm Motor Power: 4.5kw
Input Voltage: 380V 415V Or As Requirements Application: Container Load Solution
High Light:

loading dock hydraulic ramp

,

loading bay lifts

Warehouse Hydraulic Dock Lift ,Scissor Truck Lifts For Container Load Solution

Warehouse Hydraulic Dock Lift Description:

  • Warehouse hydraulic dock lift is named scissor truck lifts, which is scissor structure, and scissor material is high strong manganese steel structure.Its capacity can be varied from 300kg to 20-30tons, being applicable for kinds of working conditions. Also, it has high safety features and devices like removable safety railings, kick plate, snap chains and lip.
  • So warehouse hydraulic dock lift for container load solution, It is both have scissor lift and dock leveler function.It could be fixed in a concrete pit or directly on the ground level.
  • When warehouse don't have loading bay for dock leveler, warehouse hydraulic dock lift can be instead of dock leveler to loading cargos, the lip and platform are all anti-skid checkered surface material. In order to more suitable for your warehouse, hydraulic dock lift ,We supply customization service.



Model Capacity(KG) Min.height Max.height Platform size
L*W(mm)
Lifting time
(s)
Motor
(kw)
Self-weight (kg)
KLSJG1-5 1000 780 5000 2500*2000 62 4.0 2400
KLSJG3-1.6 3000 450 1800 3000*2000 32 4.0 1650
KLSJG3-2.5 3000 550 3050 2500*1500 50 3.0 1600
KLSJG4-3 4000 720 3000 2200*1500 30 4.0 1700
KLSJG4-5 5000 1000 5000 3000*2500 65 7.5 4500
KLSJG7-1.6 7000 980 1600 3000*2000 25 5.5 2480



Noted: Usually warehouse dock lift width is 2000mm, if over 2000mm width, it will need to spliced platform. And also can be custom as your requirements!


Main Features:

  • 1. Reinforced anti-skid checkered surface material, which can prevent people and goods slipping down, more safety
  • 2. Heavy duty & high strong manganese steel structure
  • 3. Anti-skid high-strength chequered platform, and lip for optional, need or not.
  • 4. Full width one -piece or two lip for option
  • 5. Heavy duty high pressure cylinders
  • 6. First class hydraulic power unit, good seal capacity and long life
  • 7. Safety protected 1, with Explosion Proof Valve
  • 8. Safety protected 2 for optional, with Safety toe guard to protect users if need
  • 9. Used truck loading bay equipment
  • 10. Lift ways: Electric hydraulic lifting


Parameters:

  • Electric system: Schneider contactor, CHINT electrical components ( Made In China)
  • Hydraulic System: Hycman brand power pack(Made In China) , Oiltec (Import brand) or as requirements
  • Scissor Arm Support: Hi-strength Manganese steel rectangle tube Q345 B
  • Platform Surface : Antiskid checkered plate steel
  • Main Support: 10# I beam
  • Deck lip platform steel thickness:6mm/8mm/10mm checkered plate(If need lip)
  • High-pressure Oil Pipe: Double wire-steel mesh in hydraulic rubber hose


Warehouse hydraulic dock lift  precautions:
1. Manual decline valve
2. Explosion proof  valves between oil cylinder and oil tube.
3. Number of floor layers indicator
4. Door inter-locking device if indeed need.
5. Over height protect
6. Running indicator
7. Over load alarm system if need

Optional Configuration:

  • Hydraulic Power Pack: China power pack or imported power pack as your requirements


Applications:
1. Site: Work Shop, logistic center, warehouse loading bay system, etc.
2. Equipment for warehouse application: Lifting and Loading/unloading Cargo as dock leveler function, etc.


Warehouse Hydraulic Dock Lift S
ketch:

Warehouse Hydraulic Dock Lift ,Scissor Truck Lifts For Container Load Solution 0
